Omron H3BA User Manual

36
Solid-state Timer
H3CR-F/G/H
A Wide Variety of DIN 48 x 48-mm H3CR-F Twin Timers, H3CR-G Star-delta Timers,
and H3CR-H Power OFF-delay Timers
Conforms to VDE0435/0110 and approved by UL and CSA.
Conforms to EMC standards.
Six-language instruction manual provided.
Broad Line-up of H3CR Series
H3CR
Multifunctional Timer
H3CR-A
H3CR-AS
H3CR-A8
H3CR-A8S
H3CR-A8E
H3CR-A8EL
Twin Timer
H3CR-F
H3CR-FN
H3CR-F-300
H3CR-FN-300
H3CR-F8
H3CR-F8N
H3CR-F8-300
H3CR-F8N-300
Star-delta Timer
H3CR-G8L
H3CR-G8EL
Power OFF-delay Timer
H3CR-HRL
H3CR-H8L
H3CR-H8RL
H3CR-HH3CR-GH3CR-FH3CR-A
Note: 1. H3CR-AS, H3CR-A8S: Transistor output models
2. Refer to the
H3CR-A Datasheet (L84)
for details.
11-pin model
8-pin model
8-pin with
instantaneous
contact output
model
11-pin model
8-pin model
8-pin model
8-pin model
11-pin model

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
