H5BR
H5BR
171
Dimensions
Note: All units are in millimeters unless otherwise indicated.
Panel Mounting
H5BR
M3.5 terminal screw
(effective length: 6 mm)
7 + panel thickness
Panel Mounting Adaptor
Panel Cutouts
Panel cutouts are
as shown at right.
(according to DIN43700).
Panel
72
72
6
100
67.6
1006
100 min.
82 min.
68
+0.7
-- 0
68
+0.7
-- 0

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
