Omron H3BA User Manual

H5AN
H5AN
200
A model is also available for vertical gang-mounting (Model
H5AN-4D(M)-300).
Label to cover holes
Fixture
Sunken nut
Specifications label
WARNING
Fire, Explosion, and Severe Burn Hazard
The H5AN has a built-in lithium battery. Be sure to dispose of
theoldH5ANproperly,as lithiumbatteriesarelikely toexplode
if incinerated.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
Cat. No. L50-E1-7
!

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
