Omron H3BA User Manual

H5S
H5S
250
Twelve, 25
'
4.5 elliptic holes
Mounting Track
PFP-100N/PFP-50N (Meets DIN EN 50022)
PFP-100N2 (Meets DIN EN 50022)
This dimension applies to the PFP-50N Mounting Track.
Installation
Terminal Arrangement
H5S-B Flush Mounting Models
(Rear View)
H5S-FB Surface Mounting Models
(Front View)
Note: The terminal screws are M3.5.
Connections
H5S-B Flush Mounting Models H5S-FB Surface Mounting Models
+
~
--
~
+
~
--
~
Power source
Power source

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
