H3BG
H3BG
303
Nomenclature
H3BG-8/H3BA-8(H)
H3BG-F/H3BG(-FH)
Dial Digit Display Windows
Delta Operation
Indicator
Star-delta Transfer Time
Display Window
Rated Star Time Selector
Star Operation Indicator
Star-delta Transfer Time
Selector
Rated Voltage Classification Color Code
Dial Digit Display Windows
Delta Operation Indicator
Star-delta Transfer Time
Display Window
Rated Star Time Selector
Star Operation Indicator
Star-delta Transfer Time
Selector
Rated Voltage Classification Color Code
Operation
Timing Chart
Note: 1. The terminal numbers in parentheses apply to H3BG-F(H).
2. Instantaneous contact is only available for H3BG-8H and
H3BG-FH.
