H3CR-G
H3CR-G
44
Accessories (Order Separately)
Name/specifications Models
Flush Mounting Adapter
Y92F-30
g
p
Y92F-70
Y92F-71
Mounting Track 50 cm (
l
)x7.3mm(t) PFP-50N
1m(
l
) x 7.3 mm (t) PFP-100N
1m(
l
)x16mm(t) PFP-100N2
End Plate PFP-M
Spacer PFP-S
Protective Cover Y92A-48B
Track Mounting/
Front Connecting Socket
8-pin P2CF-08
Back Connecting Socket P3G-08
Time Setting Ring Setting a specific time Y92S-27
Limiting the Setting Range Y92S-28
Panel Cover (see note) Light Gray (5Y7/1) Y92P-48GL
Black (N1.5) Y92P-48GB
Medium Gray (5Y5/1) Y92P-48GM
Hold-down Clip For PL08 and PL11 Sockets Y92H-1
For PF085A Socket Y92H-2
Note: The Time Setting Ring and Panel Cover are sold together.
Specifications
General
Item H3CR-G8L H3CR-G8EL
Functions Star-delta timer Star-delta timer with instantaneous output
Pin type 8-pin
Operating/Reset method Time-limit operation/Self-reset
Output type Time-limit: SPST-NO (star operation circuit)
SPST-NO (delta operation circuit)
Time-limit: SPST-NO (star operation circuit)
SPST-NO (delta operation circuit)
Instantaneous: SPST-NO
Mounting method DIN track mounting, surface mounting, and flush mounting
EMC Emission Enclosure: EN55011 Group 1 class A
Emission AC Mains: EN55011 Group 1 class A
Immunity ESD: IEC801-2: 4 kV contact discharge (level 2)
8 kV air discharge (level 3)
Immunity RF-interference: ENV50140: 10 V/m (80 MHz to 1 GHz) (level 3)
Immunity Conducted Disturbance: ENV50141: 10 V (0.15 to 80 MHz) (level 3)
Immunity Burst: IEC801-4: 2 kV power-line (level 3)
2 kV I/O signal-line (level 4)
Approved standards UL508, CSA C22.2 No.14, LR/NK
Conforms to VDE0435/2021, VDE0110
Conforms to EN50081-2, prEN50082-2

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
