H3CR-G
H3CR-G
50
Installation
Terminal Arrangement
H3CR-G8L H3CR-G8EL
(
~
)(
~
)
Instantaneous contact
Star
operation
contact
Delta
operation
contact
(
~
)
Star
operation
contact
Delta
operation
contact
Note: Leave terminals 1, 3, and 4 open.
Donot usethem as relay terminals.
Note: Leave terminal 4 open. Do not use
them as relay terminals.
(
~
)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Omron H3BA and is the answer not in the manual?

Omron H3BA Specifications

General IconGeneral
Time Range0.05 s to 300 h
Output TypeRelay
Contact FormDPDT
WeightApprox. 200 g
Operating Temperature-10 to 55°C
Storage Temperature-25 to 65°C
Dimensions48mm x 48mm x 78mm
TypeSolid-state timer
