H5BR
H5BR
160
Specifications
Model H5BR-B (Standard type)
Classification Digital timer
Mounting Panel mounting
External connections Screw terminals
Enclosure ratings IP54 (panel surface)
EMC Emission Enclosure: EN55011 Group 1 class A
Emission AC Mains: EN55011 Group 1 class A
Immunity ESD: IEC801-2: 4 kV contact discharge (level 2)
8 kV air discharge (level 3)
Immunity RF-interference: ENV50140: 10 V/m (80 MHz to 1 GHz) (level 3)
Immunity Conducted Disturbance: ENV50141: 10 V (0.15 to 80 MHz) (level 3)
Immunity Burst: IEC801-4: 2 kV power-line (level 3)
2 kV I/O signal-line (level 4)
Approved standards UL: File no. E41515
CSA: File no. LR22310
Conforms to EN50081-2, prEN50082-2
Display modes Elapsed time (UP), remaining time (DOWN)
Output modes A, A-1, A-2, A-3, b, b-1, d, E, F
Reset system Power reset (except A-3, b-1, and F modes), External, manual, automatic resets
(internal according to A-1, b, b-1, d, and E mode operation)
Batch counting function Yes
Sensor power supply 12 VDC
Input signals Start, reset, gate, batch count reset, key protect inputs
Input method No-voltage input: Via opening and closing of contact
Control outputs SPDT contact output and transistor output (NPN open collector)
Batch outputs Transistor output (NPN open collector)
Display LCD backlit
Digits 4 digits
Max. time settings 9.999 s (0.001 s units), 99.99 s (0.01 s units), 999.9 s (0.1 s unit), 9999 s (1 s unit),
99 min 59 s (1 s unit), 999.9 min (0.1 min unit), 9999 min (1 min unit), 99 hr 59 min
(1 min unit), 999.9 hr (0.1 hr unit), 9999 hr (1 hr unit)
Memory backup Backup time for power interruption: Approx. 10 years at 20
"
C
