Weekly Time Switch H5S
Weekly Time Switch for Various Time
Controls
A different program possible each day.
Easy-to-program using the interactive menu
system.
Multiple-day operation, cyclic and pulse-output
operation possible.
ON/OFF operations can be set in 24 steps.
Timing chart display for operation monitoring.
Two circuits can be controlled independently.
Supply voltage from 100 to 240 VAC.
Surface, flush, or track mounting possible.
RC
Ordering Information
Wiring Mounting style Model
Screw terminals Flush mounting H5S-B
Surface mounting/track mounting H5S-FB
Specifications
Time Ranges
Rated time Time setting range Time division
1 week 00:00 a.m. to 11:59 p.m. 1min
Ratings
Rated supply voltage 100 to 240 VAC (50/60 Hz), 24 VDC
Operating voltage range 85% to 110% of rated supply voltage (85 to 264 VAC (50/60 Hz))
Power consumption Approx. 3 VA
Control outputs SPST-NO x 2 circuits: 15 A at 250 VAC, resistive load

Omron H3CR-A Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Mounting Type	DIN Rail
Operating Temperature	-10°C to 55°C
Contact Form	SPDT
Number of Pins	8
Contact Rating	5A at 250VAC
Storage Temperature	-25°C to 65°C
Type	Solid State Timer
Dimensions	48 mm x 48 mm
Operating Mode	ON-delay, OFF-delay, Interval, One-shot
Operating Voltage	24V DC, 100-240V AC
