Omron H3CR-A User Manual

H5CR
H5CR
186
H5CR-L
Panel Mounting Adapter
H5CR-B
H5CR-S
Panel Cutouts
Panel cutouts are
as shown below.
(according to DIN43700).
Surface Mounting
Y92F-30
Panel mounting adapter
Panel
Y92F-30
Panel mounting adapter
Panel
Note 1. The mounting panel thickness
should be 1 to 4 mm.
2. It is possible to mount timers
side by side, but only horizontally.
48
58
6
85.9
92.8
H5CR-L
P2CF-08
58
48
6
100
58
48
664
60 min.
60 min.
A
45
+0.6
-- 0
45
+0.6
-- 0
+0.6
-- 0
A = {n x 45 + (n-1) x 3.5}
Panel
Y92F-30
Panel mounting
adapter
P3G-08
Rear surface
connection socket
44.8
44.8

Omron H3CR-A Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Mounting Type	DIN Rail
Operating Temperature	-10°C to 55°C
Contact Form	SPDT
Number of Pins	8
Contact Rating	5A at 250VAC
Storage Temperature	-25°C to 65°C
Type	Solid State Timer
Dimensions	48 mm x 48 mm
Operating Mode	ON-delay, OFF-delay, Interval, One-shot
Operating Voltage	24V DC, 100-240V AC
