H5AN
H5AN
200
A model is also available for vertical gang-mounting (Model
H5AN-4D(M)-300).
Label to cover holes
Fixture
Sunken nut
Specifications label
WARNING
Fire, Explosion, and Severe Burn Hazard
The H5AN has a built-in lithium battery. Be sure to dispose of
theoldH5ANproperly,as lithiumbatteriesarelikely toexplode
if incinerated.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
Cat. No. L50-E1-7
!

Omron H3CR-A Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Mounting Type	DIN Rail
Operating Temperature	-10°C to 55°C
Contact Form	SPDT
Number of Pins	8
Contact Rating	5A at 250VAC
Storage Temperature	-25°C to 65°C
Type	Solid State Timer
Dimensions	48 mm x 48 mm
Operating Mode	ON-delay, OFF-delay, Interval, One-shot
Operating Voltage	24V DC, 100-240V AC
