H3CR-A
H3CR-A
25
H3CR-A8/-A8S
Operating mode Timing chart
A: ON-delay
Power
Output
t
Basic operation
Power
Output relay
(NC)
Output relay
(NO) (output
indicator)
Power
indicator
t
Rt
t
Rt t - a
E: Interval
Power
Output
t
Basic operation
t
Rt
t
Rt t - a
Power
Output relay
(NC)
Power
indicator
Output relay
(NO) (output
indicator)
H3CR-A8EL/-A8E
Operating mode Timing chart
A: ON-delay
Power
Output
t
Basic operation
Power
Output relay
(NC)
Power indicator
Instantaneous
output relay (NC)
t
Rt
t
Rt t - a
Instantaneous
output relay (NO)
Output relay
(NO) (output
indicator)
E: Interval
Power
Output relay
(NC)
Power indicator
t
Rt
t
Rt t - a
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
Output relay
(NO) (output
indicator)
Power
Output
t
Basic operation

Other manuals for Omron H3CR-A

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Omron H3CR-A and is the answer not in the manual?

Omron H3CR-A Specifications

General IconGeneral
Time Range0.05 seconds to 300 hours
Output TypeRelay
Mounting TypeDIN Rail
Operating Temperature-10°C to 55°C
Contact FormSPDT
Number of Pins8
Contact Rating5A at 250VAC
Storage Temperature-25°C to 65°C
TypeSolid State Timer
Dimensions48 mm x 48 mm
Operating ModeON-delay, OFF-delay, Interval, One-shot
Operating Voltage24V DC, 100-240V AC
