Omron H3CR-A User Manual

H3CR-A
H3CR-A
27
Dimensions with Flush Mounting Adaptor
Y92F-73/70
Dimensions with Flush Mounting Adaptor
Y92F-74/71
Panel
88
58
45
!
0.15
45
!
0.15
Panel
43
!
0.2
58
45
!
0.2
50
+0.2
-- 0
Panel Cutout
Note: Themountingpanel thickness
should be 1 to 3.2 mm.
Adapter mounting hole Two, 4.5 dia.
52 to 53
76
!
0.265 to 66
R0.5 max.
R0.5 max.
45
+0.5
-- 0
55
+0.5
-- 0
Note: Themountingpanel thickness
should be 1 to 3.2 mm.
56
68
Track Mounting
*
These dimensions vary with the kind of DIN track (reference value).
100.8
*
98.5
2.3
*
H3CR-A
H3CR-AS
H3CR-A8
H3CR-A8S
H3CR-A8E
P2CF-11
P2CF-08
89.9
*
87.6
2.3
*
H3CR-
A8EL
P2CF-08
100.7* 98.4
2.3
*
H3CR-A
H3CR-AS
+
Adaptor
H3CR-A8
H3CR-A8S
H3CR-A8E
Y92F-30
P3GA-11
Y92F-30
P3G-08
80
15
15
Flush Mounting
75
H3CR-
A8EL
Y92F-30
P3G-08
15
85.4

Omron H3CR-A Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Mounting Type	DIN Rail
Operating Temperature	-10°C to 55°C
Contact Form	SPDT
Number of Pins	8
Contact Rating	5A at 250VAC
Storage Temperature	-25°C to 65°C
Type	Solid State Timer
Dimensions	48 mm x 48 mm
Operating Mode	ON-delay, OFF-delay, Interval, One-shot
Operating Voltage	24V DC, 100-240V AC
