H5RA
H5RA
274
Input Response Time
Control input Start 1
Start 2
Gate
Reset
Bank 2
Bank 3
Output inhibit
Operation check 1
Operation check 2
Batch count reset
20 ms + chattering time
Output Response Time
Control output Start 1
Start 2
Gate
Reset
Bank 2
Bank 3
Output inhibit
20 ms
Characteristics
Accuracy of operating time
!
0.1%
!
30 ms (percent of set value)
Influence of voltage
Influence of temperature
Cycle time
!
0.1%
!
10 ms (excluding initial cycle)
Reset time 1s
Memory protection against
momentary power failure
10 ms
Memory protection With built-in battery, 10 years at 25
"
C
Power-ON time 0.5 s max.
Insulation resistance 100 M
$
min. (at 500 VDC) (between current-carrying and non-current-carrying parts and
between power circuit and control circuit)
Dielectric strength 1,500 VAC, 50/60 Hz for 1 min (between current-carrying and non-current-carrying parts and
between power circuit and control circuit)
Vibration resistance Destruction: 10 to 55 Hz with 0.75-mm double amplitude for 2 hrs
Malfunction: 10 to 55 Hz with 0.5-mm double amplitude for 10 min
Shock resistance Destruction: 300 m/s
2
(approx. 30G)
Malfunction: 100 m/s
2
(approx. 10G)
Ambient temperature Operating: --10
"
Cto55
"
C
Ambient humidity Operating: 35% to 85%
Weight Approx. 1.3 kg
