Omron H3CR-A User Manual

H3BA
H3BA
289
Installation
Terminal Arrangement
H3BA H3BA-FA
Note: 1. *G: Gate:
B
--
E
*S: Start:
B
--
F
*R: Reset:
B
--
G
2. Conventional time-limit contactsare symbolizedas .
However, the contacts of H3BA are symbolized as
because timer has four operation modes.
Refer to
“Application Examples”
.
Note: 1. *G: Gate:
*S: Start:
*R: Reset:
2. Conventional time-limit contacts are symbolized as .
However, the contacts of H3BA-FA are symbolized
as because timer has four operation modes.
Refer to
“Application Examples”
.
(See
note 2)
** *
(See
note 2)
** *
(See
note 2)
H3BA-8H H3BA-8

Omron H3CR-A Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Mounting Type	DIN Rail
Operating Temperature	-10°C to 55°C
Contact Form	SPDT
Number of Pins	8
Contact Rating	5A at 250VAC
Storage Temperature	-25°C to 65°C
Type	Solid State Timer
Dimensions	48 mm x 48 mm
Operating Mode	ON-delay, OFF-delay, Interval, One-shot
Operating Voltage	24V DC, 100-240V AC
