H3CR-A
H3CR-A
30
Installation
Terminal Arrangement
H3CR-A (Contact Output) H3CR-AS (Transistor Output)
H3CR-A8 (Contact Output) H3CR-A8S (Transistor Output)
Power supply(--)(~) (+)(~)
(--)
(~)
(+)
(~)
Reset input
Start input
Gate input
(--)(~) (+)(~)Power supply
Power supply
(--)
(~)
Power supply
(+)
(~)
Reset input
Start input
Gate input
H3CR-A8EL/-A8E (Contact Output)
(--)
(~)
(+)
(~)
Power supply
