H3CR-G
H3CR-G
50
Installation
Terminal Arrangement
H3CR-G8L H3CR-G8EL
(
~
)(
~
)
Instantaneous contact
Star
operation
contact
Delta
operation
contact
(
~
)
Star
operation
contact
Delta
operation
contact
Note: Leave terminals 1, 3, and 4 open.
Donot usethem as relay terminals.
Note: Leave terminal 4 open. Do not use
them as relay terminals.
(
~
)
