Omron H3CR-A User Manual

H3CR-F/G/H
H3CR-F/G/H
61
Accessories (Order Separately)
Track Mounting/
Front Connecting Socket
P2CF-08
P2CF-11
Terminal Arrangement/
Internal Connections
(Top View)
Surface Mounting Holes
40
!
0.2
Two, 4.5 dia. or two, M4
Two, 4.5 dia. mounting holes
40
!
0.2
Eight,
M3.5 x 7.5 sems
Two, 4.5 dia.
holes
70 max.
50 max.
20.3 max.
7.8
34.5
35.4
Two, 4.5 dia.
holes
Eleven,
M3.5 x 7.5 sems
70 max.
50 max.
31.2 max.
7.8
34.5
35.4
4
4
Back Connecting Socket
P3G-08
P3GA-11
Terminal Arrangement/
Internal Connections
(Bottom View)
45
27 dia.
45
45
4.9
45
27 dia.
25.6
4.5
16.3
6.2
17
Mounting Track
PFP-100N, PFP-50N
PFP-100N2
L: Length
1 m PFP-100N
50 cm PFP-50N
1 m PFP-100N2
4.5
15 25 25 25 25
*
10 10
L
7.3
!
0.15
35
!
0.3
27
!
0.15
1
4.5
15 25 25 25 25 15
10 10
L
35
!
0.3
27
24
16
29.2
11.5

Omron H3CR-A Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Mounting Type	DIN Rail
Operating Temperature	-10°C to 55°C
Contact Form	SPDT
Number of Pins	8
Contact Rating	5A at 250VAC
Storage Temperature	-25°C to 65°C
Type	Solid State Timer
Dimensions	48 mm x 48 mm
Operating Mode	ON-delay, OFF-delay, Interval, One-shot
Operating Voltage	24V DC, 100-240V AC
