Omron H3CR-A User Manual

H3DR-F
H3DR-F
94
Timing Chart
Note: t
ON
:ONsettime
t
OFF:
OFF set time
Allow at least 0.1 s for recovery.
Power
ON
OFF
Output
0.1 s min.
ON
indicator
OFF
indicator
ON
OFF
ON
OFF
ON
OFF
Dimensions
Note: All units are in millimeters unless otherwise indicated.
Installation
Terminal Arrangement
Power
supply
+
--

Omron H3CR-A Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Mounting Type	DIN Rail
Operating Temperature	-10°C to 55°C
Contact Form	SPDT
Number of Pins	8
Contact Rating	5A at 250VAC
Storage Temperature	-25°C to 65°C
Type	Solid State Timer
Dimensions	48 mm x 48 mm
Operating Mode	ON-delay, OFF-delay, Interval, One-shot
Operating Voltage	24V DC, 100-240V AC
