Omron H3CR-AS - Page 13

H3CR-A
H3CR-A
15
H3CR-A8E
Operating
mode
Timing chart
A:
ON-delay
Power
Output
t
Basic operation
Power
Output relay
(NC)
Power indicator
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
Output relay
(NO) (output
indicator)
B
2
:
Flicker ON
start
Power
Output relay
(NC)
Power indicator
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
Output relay
(NO) (output
indicator)
Power
Output
t
Basic operation
ttt
E:
Interval
Power
Output relay
(NC)
Power indicator
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
Output relay
(NO) (output
indicator)
Power
Output
t
Basic operation
J:
One-shot
output
Power
Output relay
(NC)
Power indicator
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
Output relay
(NO) (output
indicator)
Power
Output
t
Basic operation
1±0.6 s
(Fixed)
(Fixed) (Fixed)
