H3CR-G
H3CR-G
29
Solid-state Star-delta Timer H3CR-G
DIN 48 x 48-mm Star-delta Timer
A wide star-time range (up to 120 seconds) and
star-delta transfer time range (up to 0.5 seconds).
RC
Ordering Information
Outputs Supply
voltage
8-pin models
T
ime-limit contact
100 to 120 V
AC H3CR-G8L
200 to 240 V
AC
T
ime-limit contact and instantaneous contact
100 to 120 V
AC H3CR-G8EL
200 to 240 V
AC
Note:
Specify both the model number and supply voltage when ordering.
Example: H3CR-G8L 100 to 120 V
AC
Supply voltage
Model Number Legend:
H3CR -
1 23
1.
Classification
G:
Star-delta timer
2. Configuration
8: 8-pin socket
3. Outputs
None:
Star-delta operation contact
E:
Star-delta operation contact and instantaneous contact
4. Dimensions
L:
Long-body model
4
To Next Page
