Omron H3CR-AS User Manual

H3CR
H3CR
47
Accessories (Order Separately)
Note: The undermentioned is common for all H3CR models.
Note: All units are in millimeters unless otherwise indicated.
Flush Mounting Adaptor
Y92F-30
Panel Cutout
Note: The adapters for two or more timers mounted in a vertical line are different in
orientation from those mounted in a horizontal line.
N can be obtained as follows (n: the number of H3CR models arranged side by side)
Without a Cover: N = (48n - 2.5)
+1
/
-0
With the Protective Cover: N = (51n - 5.5)
+1
/
-0
With the Panel Cover: N = (50n - 4.5)
+1
/
-0
0.5 R max.
45
+0.6
–0
45
+0.6
–0
(N)
58 52
42
48
Panel
Y92F-70/-73
Y92F-71/-74
Panel
88
58
45±0.15
Panel
43±0.2
58
45±0.2
50
+0.2
–0
Panel Cutout
Note: The
mounting panel thickness
should be 1 to 3.2 mm.
Adapter mounting hole Two, 4.5 dia.
52 to 53
76±0.265 to 66
R0.5 max.
R0.5 max.
45
+0.5
–0
55
+0.5
–0
Note: The mounting panel thickness
should be 1 to 3.2 mm.
56
68
45±0.15
