Omron H3CR Series - Engineering Data, Nomenclature, and Operation (H3 CR-F); Performance Data and Controls; Block Diagrams and I;O Functions

H3CR-F
H3CR-F
28
Dimensions
Note: All units are in millimeters unless otherwise indicated.
H3CR-F
H3CR-FN
H3CR-F-300
H3CR-FN-300
H3CR-F8
H3CR-F8N
H3CR-F8-300
H3CR-F8N-300
66.6
0.7
17.4
37 dia.
52.3
6
5.7
R1.3
14 dia.
44.8 x 44.8
66.6
0.7
17.4
37 dia.
52.3
6
5.7
R1.3
14 dia.
44.8 x 44.8
48
48
48
48
11 pins
8 pins
Dimensions with Front Connecting Socket
P2CF-08-j/P2CF-11-j
*
These dimensions vary with the kind of DIN track (reference value).
103.2* 100.9
2.3
*
P2CF-11
P2CF-08
92.3* 90.0
2.3
*
Y92F-30
P3GA-11
Y92F-30
P3G-08
80
17.4
17.4
Dimensions with Back Connecting Socket
P3G-08/P3GA-11
75
H3CR-F
H3CR-FN
P2CF-11-E P2CF-08-E
H3CR-F8
H3CR-F
H3CR-FN
H3CR-F8
H3CR-F8N
H3CR-F8N
81.5
81.5
(When
Y92A-48G
mounted)
(When
Y92A-48G
mounted)
Installation
Terminal Arrangement
Power supply
(+)
(~)
(–)
(~)
Power supply
(–)(~)
(+)(~)
H3CR-F
H3CR-FN
H3CR-F-300
H3CR-FN-300
H3CR-F8
H3CR-F8N
H3CR-F8-300
H3CR-F8N-300
Note: Leave terminals 5, 6, and 7 open.
Do not use them as relay terminals.
