Omron H3CR Series - Ordering Information (H3 CR-G); H3 CR-G Output and Model Variants; Model Number Legend

H3CR-G
H3CR-G
30
Accessories (Order Separately)
Name/specifications Models
Flush Mounting Adapter
Y92F-30
gp
Y92F-70
Y92F-71
Mounting Track
50 cm (l) x 7.3 mm (t)
PFP-50N
1 m (l) x 7.3 mm (t)
PFP-100N
1 m (l) x 16 mm (t)
PFP-100N2
End Plate PFP-M
Spacer PFP-S
Protective Cover Y92A-48B
Track Mounting/
FtC tiSkt
8-pin P2CF-08
g
Front Connecting Socket
8-pin, finger safe type P2CF-08-E
Back Connecting Socket
8-pin P3G-08
g
8-pin, finger safe type P3G-08 with Y92A-48G (see note 1)
Time Setting Ring Setting a specific time Y92S-27
Limiting the setting range Y92S-28
Panel Cover (see note 2) Light gray (5Y7/1) Y92P-48GL
Black (N1.5) Y92P-48GB
Medium gray (5Y5/1) Y92P-48GM
Hold-down Clip (see note 3) For PL08 and PL11 Sockets Y92H-1
For PF085A Socket Y92H-2
Note: 1. Y92A-48G is a finger safe terminal cover which is attached to the P3G-08 Socket.
2. The Time Setting Ring and Panel Cover are sold together.
3. Hold-down Clips are sold in sets of two.
Specifications
General
Item H3CR-G8L H3CR-G8EL
Functions Star-delta timer Star-delta timer with instantaneous output
Pin type 8-pin
Operating/Reset method Time-limit operation/Self-reset
Output type Time-limit: SPST-NO (star operation circuit)
SPST-NO (delta operation circuit)
Time-limit: SPST-NO (star operation circuit)
SPST-NO (delta operation circuit)
Instantaneous: SPST-NO
Mounting method DIN track mounting, surface mounting, and flush mounting
Approved standards UL508, CSA C22.2 No.14, NK, Lloyds
Conforms to EN61812-1 and IEC60664-1 (VDE0110) 4kV/2.
Output category according to EN60947-5-1.
Time Ranges
Time unit Star operation time ranges
Full scale setting
6 0.5 to 6 s
g
12 1 to 12 s
60 5 to 60 s
120 10 to 120 s
Star-delta transfer time Programmable at 0.05 s, 0.1 s, 0.25 s or 0.5 s
