H3CR
H3CR
47
Track Mounting/Front Connecting Socket
P2CF-08
P2CF-08-E (Finger Safe Terminal Type)
Conforming to VDE0106/P100
Terminal Arrangement/
Internal Connections
(Top View)
Surface Mounting Holes
40±0.2
Two, 4.5 dia. or two, M4
Eight,
M3.5 x 7.5 sems
Two, 4.5 dia.
holes
70 max.
50 max.
20.3 max.
7.8
3 4.5
35.4
4
50 max.
40±0.2
70 max.
Eight,
M3.5 x 7.5 sems
Two, 4.5 dia.
holes
7.8
4
35.4
21.5 max.
20.3
19
3
1.3
5 4.5
Track Mounting/Front Connecting Socket
P2CF-11
Terminal Arrangement/
Internal Connections
(Top View)
Surface Mounting Holes
Two, 4.5 dia. or two, M4
40±0.2
Two, 4.5 dia.
holes
Eleven,
M3.5 x 7.5 sems
70 max.
50 max.
31.2 max.
7.8
3 4.5
35.4
4
P2CF-11-E (Finger Safe Terminal Type)
Conforming to VDE0106/P100
Two, 4.5 dia.
holes
Eleven,
M3.5 x 7.5 sems
7.8
70 max.
4
40±0.2
50 max.
35.4
31.2 max.
30
5 4.5
3
1.2
