Omron H3CR Series - Connecting Sockets and Terminal Covers; P3 G-08; P3 GA-11 Socket Details; Y92 A-48 G Terminal Cover; Mounting Tracks, End Plates, and Spacers

H3CR
H3CR
48
Back Connecting Socket
P3G-08
Terminal Arrangement/
Internal Connections
(Bottom View)
45
27 dia.
45
4.9
17
P3GA-11
Terminal Arrangement/
Internal Connections
(Bottom View)
45
45
27 dia.
25.6
4.5
16.3
6.2
Finger Safe Terminal Cover
Conforming to VDE0106/P100
Y92A-48G
(Attachment for P3G-08/P3GA-11
Socket)
Twelve, 6.4 dia. holes
34
47.7 x 47.7 48 x 48
47.4
16.5
24.6
27.6
Mounting Track
PFP-100N, PFP-50N
PFP-100N2
4.5
15 25 25 25 25
10 10
7.3±0.15
35±0.3
27±0.15
1
4.5
15 25 25 25 25 15
10 10
35±0.3
27
24
16
29.2
1 1.5
1,000 (500)
(see note)
15 (5)
(see note)
Note: The value shown in parentheses are for the
PFP-50N.
1,000
End Plate
PFP-M
Spacer
PFP-S
50
11.5
M4 x 8
pan head
screw
10
6.2
1.8
1
35.5 35.3
1.8
1.3
4.8
5
16
12
44.3
34.8
16.5
10
