Solid-state Power OFF-delay Timer H3DE-H B-75
Timers
Solid-state Power OFF-delay Timer
H3DE-H
• Two delay-time models available.
0.1 to 12 seconds (S Series)
1 to 120 seconds (L Series)
• Covers wide range of supply voltage.
Model Number Structure
■ Model Number Legend
Ordering Information
■ List of Models
■ Accessories (Order Separately)
H3DE -
1
1. H: Power OFF-delay timer
Supply voltage Model
S Series (time range: 0.1 to 12 s) L Series (time range: 1 to 120 s)
100 to 120 VAC H3DE-H H3DE-H
200 to 230 VAC
24 VAC/VDC
48 VAC/VDC
Time span code
Supply voltage
Note: Specify both the model number and supply voltage when ordering.
Example: H3DE-H 24 VAC/DC S
Mounting Track 50 cm (l) x 7.3 mm (t) PFP-50N
1 m (l) x 7.3 mm (t) PFP-100N
1 m (l) x 16 mm (t) PFP-100N2
End Plate PFP-M
Spacer PFP-S
