H5CR H5CR
7
■ TIMERS
Dimensions
Unit: mm (inch)
Economy Models H5CR-L, H5CR-LS
48
(1.89)
48
(1.89)
Short Body Models H5CR-S, H5CR-SS
48
(1.89)
48
(1.89)
M3.5 terminal screw,
effective length: 6 mm (0.24 in)
Standard Models H5CR-B, H5CR-BS
48
(1.89)
48
(1.89)
6
(0.24)
100
(3.94)
44.8
(1.76)
44.8
(1.76)
64
(2.52)
6
(0.24)
M3.5 terminal screw,
effective length: 6 mm (0.24 in)
84.0
(3.31)
14.3
(0.56)
6
(0.24)
0.7
(0.03)
63.7
(2.51)
44.8
(1.76)
■ ACCESSORIES
The diagram below shows the adapter on an H5CR-L timer. The mounting depths for H5CR-B and H5CR-S are the same as shown in
Timer Dimensions .
6
(0.24)
85.9
(3.38)
Panel
Y92F-30
Panel mounting
adapter
P3G-08
Rear surface
connection socket
58
(2.28)
48
(1.89)
Panel Cutouts
Panel cutouts shown at right
conform to DIN 43700.
60 min.
(2.36)
-0
45
+0.6
-0
45
+0.6
60 min.
(2.36)
Note: 1. The mounting panel thickness
should be 1 to 4 mm (0.04 to 0.16 in).
2. It is possible to mount timers side by
side, but only horizontally.
A = [n x 45 (n -1) x 3.5]
+0.6
-0
Y92F-30 Panel Mounting Adaptor
