H5CR H5CR
9
Two mounting clips help the soft plastic cover Y92A-48F1 fit
snugly over the front of the timer to protect against dirt and
water. Timer settings can be changed when the cover is on.
The cover is intended for use in areas where unusual service
conditions do not exist.
Y92A-48F1 Soft plastic cover
50.5
(1.99)
50.5
(1.99)
Y92A-48T Terminal cover
47.2
(1.86)
47.2
(1.86)
The terminal cover protects wiring connections on the
Standard and Short Body models.
PFP-100N, PFP-50N Mounting Track
PFP-100N2 Mounting Track
4.5
(0.18)
7.3±0.15
35±0.3
27±0.15
1
(0.04)
L
15 25
10
25 25
25
10
4.5
(0.18)
15 25
10
25
L
25 25 15
10
35±0.3
1
(0.04)
16
(0.63)
29.2
(1.15)
1.5
(0.06)
27
24
PFP-M End Plate
PFP-S Spacer
50
(1.97)
11.5
(0.45)
10
(10.39)
M4 x 8
pan head
screw
4.8 (0.19)
1.3 (0.05)
1.8
1
35.5
35.3
(1.39)
10
(0.39)
6.2
(0.24)
1.8
(0.07)
5
(0.20)
16
(0.63)
12
34.8
(1.37)
16.5
(0.65)
44
(1.74)
1 m PFP-100N
50 cm PFP-50N
1 m PFP-100N2
L: Length
