13
H5CRH5CR
■ Dimensions with Y92F-30 Flush Mounting Adapter
48
58
6
85.9
58
48
6
100
92.8
A
H5CR-L
H5CR-B
H5CR-S
Panel Cutouts
Panel cutouts are
as shown below.
(according to DIN43700).
Surface Mounting
Y92F-30
Flush mounting adapter
Panel
Y92F-30
Flush mounting adapter
Panel
Note 1. The mounting panel thickness
should be 1 to 4 mm.
2. It is possible to mount timers
side by side, but only horizontally.
H5CR-L
P2CF-08
58
48
6
64
60 min.
60 min.
45
+0.6
-0
45
+0.6
-0
+1
0
A = {48n - 2.5 + (n - 1) x 4}
Panel
Y92F-30
Flush mounting
adapter
P3G-08
Rear surface
connection socket
44.8 x 44.8
With Y92A-48F1 attached.
44.8 x 44.8
+1
0
A = (51n - 5.5)
With Y92A-48 attached.
