Omron H5CR User Manual

14
H5CRH5CR
■ Accessories (Order Separately)
Eight,
M3.5 x 7.5 sems
Two, 4.5 dia.
holes
70 max.
50 max.
20.3 max.
7.8
3
4.5
35.4
4
Track Mounting/Front Connecting Socket
P2CF-08
P2CF-08-E (Finger Safe Terminal Type)
Conforming to VDE0106/P100
Terminal Arrangement/
Internal Connections
(Top View)
Surface Mounting Holes
40 ± 0.2
Two, 4.5 dia. or two, M4
50 max.
40 ± 0.2
70 max.
Eight,
M3.5 x 7.5 sems
Two, 4.5 dia.
holes
7.8
4
35.4
21.5 max.
20.3
19
3
1.3
5
4.5
45
27 dia.
45
4.9
17
Back Connecting Socket
P3G-08
Terminal Arrangement/
Internal Connections
(Bottom View)
Finger Safe Terminal Cover
Conforming to VDE0106/P100
Y92A-48G
(Attachment for P3G-08 Socket)
Y92A-48T
(Attachment for H5CR-B @ /-S @ )
Hard Cover
Y92A-48
Soft Cover
Y92A-48F1
Twelve, 6.4 dia. holes
34
47.7 x 47.7
48 x 48
47.4
16.5
24.6
27.6
