Multifunction Digital Timer H5CX-A/-L (Twin Timer Function) 29
Operation in Run Mode
Present Value and OFF Set Time
The present value is displayed in the main display and the OFF set
time is displayed in the sub-display. “SET1” lights at the same time.
Present Value and ON Set Time
The present value is displayed in the main display and the ON set
time is displayed in the sub-display. “SET2” lights at the same time.
Present value
OFF set time
Present value
ON set time
Set the digits for the OFF set time using the corresponding keys.
Set the digits for the ON set time using the corresponding keys.
