Cam Positioner H8PS 13
Encoder Connecting Direction
■ Accessories (Order Separately)
Parallel Input Adapters
Y92C-30
This Adapter enables two H8PS Cam Positioners to share signals
from an Encoder.
Use the cable marked with a triangle when connecting only one
H8PS Cam Positioner to the Parallel Input Adapter.
• Panel Surface Mounting
• Panel Back Mounting
Encode
r
Output cable
Encode
r
Encode
r
Output cable
Encoder
H8PS-8B@
H8PS-8BF@
H8PS-16B@
H8PS-32B@
H8PS-16BF@
H8PS-32BF@
Connected to the H8PS.
Connected to the H8PS.
Y92C-30
From the Dedicated Absolute Encoder
R6.5
14 dia.36
40.4 6.5
246089
47 1,030
15 37
8.5 dia.
17 dia.
2
6
11.3
9
74
±
1
Two, M4 tap holes
Front
M4 screw (included)
36
74±
1
Two, 4.3 dia. holes
Back
M4 screw (included)
M4 nut (included)
36
