Cam Positioner H8PS 3
Specifications
■ Ratings
Item H8PS-@BH8PS-@BF H8PS-@BP H8PS-@BFP
Rated supply voltage 24 VDC
Operating voltage range 85% to 110% of rated supply voltage
Mounting method Flush mounting Surface mounting,
track mounting
Flush mounting Surface mounting,
track mounting
Power consumption Approx. 4.5 W at 26.4 VDC for 8-output models
Approx. 6.0 W at 26.4 VDC for 16-/32-output models
Inputs Encoder input Connections to a dedicated absolute encoder
External
inputs
Input
signals
8-output Models: None
16-/32-output Models: Bank inputs 1/2/4, origin input, start input
Input type No voltage inputs: ON impedance:1 k
Ω max. (Leakage current: approx. 2 mA at 0 Ω)
ON residual voltage: 2 V max., OFF impedance: 100 k
Ω min., Applied voltage: 30 VDC max.
Minimum input signal width: 20 ms
Outputs Cam outputs
RUN output
NPN open-collector transistor outputs
30 VDC max.,
100 mA max. (Do not exceed 1.6 A total for all cam
outputs and the RUN output.),
residual voltage: 2 VDC max.
PNP open-collector transistor outputs
30 VDC max. (26.4 VDC for 16-/32-output Models),
100 mA max. (Do not exceed 1.6 A total for all cam
outputs and the RUN output.),
residual voltage: 2 VDC max.
Pulse output NPN open-collector transistor output
30 VDC max.,
30 mA max.,
residual voltage: 0.5 VDC max.
PNP open-collector transistor output
30 VDC max. (26.4 VDC for 16-/32-output Models)
30 mA max.,
residual voltage: 2 VDC max.
Number of outputs 8-output Models: 8 cam outputs, 1 RUN output, 1 pulse output
16-output Models: 16 cam outputs, 1 RUN output, 1 pulse output
32-output Models: 32 cam outputs, 1 RUN output, 1 pulse output
Number of banks 8 banks (for 16-/32-output Models only)
Display method 7-segment, negative transmissive LCD (Main Display: 11 mm (red), Sub-display: 5.5 mm (green))
Memory backup method EEPROM (overwrites: 100000 times min.) that can store data for 10 years min.
Ambient operating
temperature
−10 to 55°C (with no icing or condensation)
Storage temperature
−25 to 65°C (with no icing or condensation)
Ambient humidity 25% to 85%
Degree of protection Panel surface: IP40, Rear case: IP20
