TECHNICAL
NOTE
Quantity Part Number Description Version
6 7412-2000-2005 MicroHAWK ID-40, SXGA, HD, Autofocus, WHT, HS, X 1.3.0.3009
6 97-000012-01 Power Supply, 100-240 VAC, +24 VDC, M12 12-Pin Socket
6 61-000163-03 QX Cordset, Host, Ethernet, M12 8-Pin Plug (Screw-On)-to-RJ45, 3 m
6 98-9000054-01 Kit, Mounting, APG, MicroHAWK
1 NJ301-1100 NJ301 Machine Automation Controller 1.16
1 HMC-SD291 2 GB Memory Card
1 NJ-PA3001 NJ Power Supply Unit
1 NX-ECC202 EtherCAT Coupler Unit 1.2
1 NX-ID5142-1 16-Point - DC Input Module 1.0
1 NX-OD4256 8-Point - Transistor Output, DC 1.0
1 S8VK-G12024 NA Power Supply
1 XS5W-T421-EMD-K EtherCAT I/O Cable
1 PFP-50N DIN Track - Length: 0.5 m; Height: 7.3 mm
1 NA5-9W001B 9” NA-HMI Panel
1 E3Z-T81 E3Z Through-Beam, Infrared, Pre-Wired
3 XS6W-6LSZH8SS200CM-Y Cat 6A Ethernet Cable, 2M, Yellow
1 N/A 16-Port 100 Mbps Ethernet Switch
Production Rates
Software
Conguration 1 – NJ301 Controller
Technical Note: MicroHAWK ID-40 360
º
Barcode Reading Solution
• Solution tested at 100 FPM for high-contrast barcodes.
• Typical read rate: 1 per second.
• SYSMAC Studio, Standard Edition, version 1.23.
• Internet browser to connect the MicroHAWK ID-40 to WebLink.
Hardware
This solution can be implemented on NJ or NX machine controllers. Two example hardware equipment lists are
provided. Conguration 1 uses an NJ301 and Conguration 2 uses an NX1P2.
