8-1 Key to Programs
The following programs include all the commands that can be used with the the
NT600M.
8-1-1 Use of Programs
The sample program appears as follows on the screen.
Send command column
Menu bar Sub-menu Parameter input column
Run confirm column
Receive command
display column
Use the program as shown below.
Interrupt display when
command received
[ESC]
[ESC]
[ESC]
Execute program
Select type of send
command
Select send command
Input parameter
Confirm send command
Execute transfer
command
End program
Main Menu
Sub-menu
Input parameter column
Send command column,
confirm execution
Up, Down, Left, Right keys: select item
Enter key: confirm
[Esc]: stop
Note
1. Modify this program for use with a PT other than the NT600M.
2. This sample program is written in N88 BASIC (86) (NEC) for a PC-9801
computer. Modify this program for use with any other computer language or
computer such as an IBM PC/AT or compatible.
3. The interval between parameter input and command transmission is a hold
interval for interrupt processing of the received command. If an interrupt is
permitted between the interval of parameter input and a command is re-
ceived, all subsequent receive interrupts are displaced. If this occurs, send
an enquiry command to read all the accumulated receive data.
4. When a parameter is input, no check is made that the parameter is in the
permitted range. Make sure that parameters are input within the permitted
range.
( $
Section 8-1
