A - 47
Appendices
NX-series Position Interface Units User’s Manual (W524)
A-2 Object Lists
A
A-2-3 SSI Input Units
• The following table shows the settings of the Baud Rate object.
• Set this object to the wait time until SSI communications are started from the time that I/O power is
supplied to the SSI Encoder Unit after the power supply is turned ON or after the NX Unit is restarted
after the SSI Input Unit starts operation.
• The following table shows the settings for the SSI Communications Start-up Time object.
Other Objects
Index
(hex)
Subin-
dex
(hex)
Object name Default
Data
range
Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5000 --- Baud Rate --- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 Baud Rate 4 0 to 7 --- USINT RW No Y
02
Ch2 Baud Rate
*2
*2. This object does not exist on the NX-ECS112.
4 0 to 7 --- USINT RW No Y
Set value Description
0 100 kHz
1 200 kHz
2 300 kHz
3 400 kHz
4 500 kHz
5 1.0 MHz
6 1.5 MHz
7 2.0 MHz
Index
(hex)
Subin-
dex
(hex)
Object name Default
Data
range
Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
5001 --- SSI Communications
Start-UP Time
--- --- --- --- --- --- ---
00 Number of Entries
*1
*1. The values for the NX-ECS112 are 1. The values for the NX-ECS212 are 2.
*1 --- USINT RO No ---
01 Ch1 SSI Communications
Startup Time
0 0 to 3 --- USINT RW No Y
02 Ch2 SSI Communications
Startup Time
*2
*2. This object does not exist on the NX-ECS112.
0 0 to 3 --- USINT RW No Y
Set value Description
0 2,000 ms
1 1,050 ms
2 500 ms
3 No delay
