1 Features and System Configuration
1 - 20
NX-series Position Interface Units User’s Manual (W524)
To set up the Unit configuration information and NX Unit settings of the Slave Terminal, connect the
Sysmac Studio to the EtherCAT Coupler Unit through the USB port. Use Sysmac Studio version 1.06 or
higher.
Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504) for information on the func-
tions that you can use.
Connect the Sysmac Studio to the EtherCAT Coupler Unit through the USB port.
Refer to the NX-series EtherCAT Coupler Unit User’s Manual (Cat. No. W519) for information on the
connection methods.
Sysmac Studio Connection to the EtherCAT Coupler Unit
