Timing Chart

E-STOP S1 (Si0)

E-STOP S1 (Si1)

Reset S2

KM1

KM2

EDM feedback

Reset ON

(Rising Edge)

E-STOP pushed

E-STOP released

Discrepancy time

Discrepancy error

TEDM TEDM TEDM TEDM TEDM

EDM error

EDM error reset

Activate OFF→ON

MAX_Feedback_Time (TEDM)

Discrepancy

error reset

Safety connection status

(Unit 2 and Unit 3)

Safety I/O Terminal & I/O Map Setting

Safety I/O Terminal Settings

Appendices

A - 31

NX-series Safety Control Unit User's Manual (Z930)

A-3 Application Examples

A-3-1 Emergency Stop Pushbutton Switches
