Omron NX1 Series - Basic System Configuration

Machine Automation Controller NX1
2
System Configuration
Basic System Configuration
EtherNet/IP
LAN
Slave Terminal
Servo Drives/
Encoder input slaves
General-purpose
slaves
Support Software
EtherCAT
CPU Rack
NX Units
EtherCAT Network
configuration
Built-in EtherNet/IP port 1
Built-in EtherNet/IP port 2
Built-in EtherCAT port
NX Unit configuration
NX-series
NX102 CPU Unit
Note: When I/O power is supplied from the
NX bus to NX Units connected to the
CPU Unit, one or more NX-PF
Additional I/O Power Supply Units
may need to be added.
See page 12 for details.
