3 - 31
3 Specifications
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
3-3 Linear Motor Specifications
3
3-3-2 Performance Specifications of Iron-core Linear Motors
*1 This shows a value measured when the Motor Coil Unit is at 100°C and the Magnet Track is at 25°C. As a
cooling condition, attach the Motor Coil Unit to the center of an aluminum radiator plate (moving table) of the
specified dimensions, shown in the above table.
*2 The Motor Coil Unit is subjected to a temperature rise of 6 K/s.
R88L-EC-FW-1112/-1115
Motor Coil Unit (R88L-EC-FW-îš…-ANPC)
1112 1115
Servo Drives (R88D-îš…-ECT-L)
KN15H KN30F KN15H KN30F
Applicable Servo Drives input voltage 200 VAC 400 VAC 200 VAC 400 VAC
Maximum speed (100 VAC) m/s – – – –
Maximum speed (200 VAC) m/s 2 – 2 –
Maximum speed (400 VAC) m/s – 4 – 4
Continuous force
*1
N 608 760
Momentary maximum force
*2
N 1,600 2,000
Continuous current
*1
Arms 6.5 8.2
Momentary maximum current
*2
Arms 20 25
Motor force constant N/Arms 93.0 93.0
Back electromotive force V·s/m 31 31
Motor constant N/√W 41.47 46.37
Phase resistance Ω 1.6 1.29
Phase inductance mH 12.8 10.3
Electrical time constant ms 8 8
Maximum continuous power
consumption
W 279 349
Thermal resistance K/W 0.23 0.18
Thermal time constant s 126 126
Magnetic attraction force N 3,640 4,440
Magnetic pole pitch mm 24 24
Mass (except cables) kg 4.45 5.45
Radiator plate dimensions mm 371 x 330 x 14 371 x 330 x 14
To Next Page
