Regulations and Standards
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
*1 The R88D-KT20 and lower capacity Servo Drives are UL-listed.
The R88D-KT30 and higher capacity Servo Drives are UL-recognized.
This product complies with the UL 508C standard (file No. E179149) only when the following two
installation conditions are met.
•
Use the Servo Drive in an environment rated as Pollution Degree 2 or Pollution Degree 1 defined in
IEC60664-1. For example, the product meets this requirement when installed inside an IP54 control panel.
• Be sure to connect between the power supply and the noise filter a circuit breaker or fuse that bears
the mark (which means a UL-listed product).
Refer to the following table for the rated current of the circuit breaker/fuse.
For wiring, use a copper conductor wire with a temperature rating of 75 ºC or higher.
• The G5-series Servo Drives comply with the Korean Radio Regulations (KC).
• The G5-series Servomotors and Linear Motors are exempt from the Korean Radio Regulations (KC).
• Servo Drives conform to the SEMI F47 standard for momentary power interruptions (voltage sag
immunity) for no-load or light-load operation.
• This standard applies to semiconductor manufacturing equipment.
Precautions for Correct UsePrecautions for Correct Use
• It does not apply to Servo Drives with single-phase 100-V specifications or with 24 VDC
specifications for the control power input.
• Always perform evaluation testing for SEMI F47 compliance in the actual system.
UL and cUL Standards
Standard Product Applicable standards File number
UL standards AC Servo Drives UL 508C
E179149
*1
CSA standards AC Servo Drives CSA C22.2 No. 14 E179149
Servo Drive model Circuit breaker rated current [A]
R88D-KN01L-ECT-L 10
R88D-KN02L-ECT-L
R88D-KN04L-ECT-L
R88D-KN01H-ECT-L
R88D-KN02H-ECT-L
R88D-KN04H-ECT-L
R88D-KN08H-ECT-L 15
R88D-KN10H-ECT-L
R88D-KN15H-ECT-L 20
R88D-KN06F-ECT-L 15
R88D-KN10F-ECT-L
R88D-KN15F-ECT-L
R88D-KN20F-ECT-L 20
R88D-KN30F-ECT-L 30
Korean Radio Regulations (KC)
SEMI F47
