A-3 Sysmac Error Status Codes
A
A-3-2 Error Description
Event name Servo Drive Overheat Event code 34E1 0000 hex
Description The temperature of the Servo Drive radiator or power elements exceeded the specified value.
Source
EtherCAT Master Function Module
Source
details
Slave Detection
timing
Continuously
Error
attributes
Level
Minor fault
Recovery
Error reset
(after cycling slave
power)
Log category
System
Effects
User program
Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators
EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
–––
System
-defined
variables
Variable Data type Name
None – –
Cause and
correction
Assumed cause Correction Prevention
The ambient temperature of the
Servo Drive exceeded the
specified value.
Improve the ambient temperature
and the cooling conditions of the
Servo Drive.
Check the ambient temperature of
the Servo Drive and set up the
necessary cooling conditions.
Overload Increase the capacities of the
Servo Drive and the motor. Or,
increase the setting of the
acceleration/deceleration time and
lighten the load.
Increase the setting of the
acceleration/deceleration time
and lighten the load as much as
possible.
Attached
information
None
Precautions/
Remarks
“15” is displayed on the Servo Drive front panel and F015 is given as the AlarmCode (4001 hex).
