G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
Event name Interface Input Duplicate Allocation Error 1 Event code 3845 0000 hex
Description There is a duplicate setting in the input signal (IN1, IN2, IN3, and IN4) function allocations.
Source
EtherCAT Master Function Module
Source
details
Slave
Detection
timing
When
establishing
communications
after turning ON
power to the
slave or when
transferring
EtherCAT
Configuration
Setup
Error
attributes
Level
Minor fault
Recovery
Error reset
(after cycling slave
power)
Log category
System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators
EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
–––
System
-defined
variables
Variable Data type Name
None – –
Cause and
correction
Assumed cause Correction Prevention
There is a duplicate setting in the
input signal (IN1, IN2, IN3, and
IN4) function allocations.
Allocate the functions to the
connector pins so that each
function is allocated only once.
Allocate the functions to the
connector pins so that each
function is allocated only once.
Attached
information
None
Precautions/
Remarks
“33” is displayed on the Servo Drive front panel and F033 is given as the AlarmCode (4001 hex).
Event name Interface Input Duplicate Allocation Error 2 Event code 3846 0000 hex
Description There is a duplicate setting in the input signal (IN5, IN6, IN7, and IN8) function allocations.
Source
EtherCAT Master Function Module
Source
details
Slave
Detection
timing
When
establishing
communications
after turning ON
power to the
slave or when
transferring
EtherCAT
Configuration
Setup
Error
attributes
Level
Minor fault
Recovery
Error reset
(after cycling slave
power)
Log category
System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators
EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
–––
System
-defined
variables
Variable Data type Name
None – –
Cause
and
correction
Assumed cause Correction Prevention
There is a duplicate setting in the
input signal (IN5, IN6, IN7, and
IN8) function allocations.
Allocate the functions to the
connector pins so that each
function is allocated only once.
Allocate the functions to the
connector pins so that each
function is allocated only once.
Attached
information
None
Precautions/
Remarks
“33” is displayed on the Servo Drive front panel and F133 is given as the AlarmCode (4001 hex).
