Omron R88D-KN10F-ECT-L User Manual

2 - 23
2 Models and External Dimensions
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
2-4 External and Mounting Dimensions
2
2-4-2 Linear Motor Dimensions
Magnet Track
*3 Use M5 low head allen head bolts.
Model L2 [mm] L3 [mm] Number of holes [N] Mass [kg]
R88L-EC-FM-11192-A 192 144 8 Approx. 2.12
R88L-EC-FM-11288-A 288 240 12 Approx. 3.18
1212
4826 48
88º
120 130
N-
Ø
6
*3
L2
48 4848 (22)
L3
12.2
Ø 5 Depth 8
12
5.5
5
Depth
8
Enlarged view of portion B
B
