Omron R88D-KT Series User Manual

4-24
4-2 Wiring
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
4
System Design
Terminal Block Specifications (TB2)
Precautions for Correct Use
Never connect an External Regeneration Resistor between the B1 and NC terminals.
Symbol Name Function
L1
Main circuit power supply
input
R88D-KT@F (3 to 5 kW): 3-phase 380 to 480 VAC (323 to 528 V)
50/60 Hz
L2
L3
B1
External Regeneration
Resistor connection
terminals
Normally B2 and B3 are connected. Do not short B1 and B2. Doing
so may cause malfunctions.
If there is high regenerative energy, remove the short-circuit bar
between B2 and B3 and connect an External Regeneration
Resistor between B1 and B2.
B3
B2
NC Do not connect.
U
Motor connection
terminals
Red These are the output terminals to the Servomotor.
Be sure to wire them correctly.
VWhite
WBlue
Green/
Yellow
Frame ground This is the ground terminal. Ground to 10 Ω or less.
