Omron R88D-KT Series User Manual

2-32
2-4 External and Mounting Dimensions
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
3-phase 200 VAC: R88D-KT30H/-KT50H (3 to 5 kW)
Wall Mounting
External dimensions
Mounting dimensions
R2.6
R2.6
φ5.2
R2.6 R2.6
φ5.2
212
3
130
100
15
65
5.2
5.2
220 240 250
5.2
5.2
65
15
100
70
6-M4
50
240
100
130
15
220
