Omron SYSMAC C200H-MAD01

Appendix DData Memory Coding Sheet
123
07 06 05 04 03 02 01 00
Input 8 Input 7 Input 6 Input 5 Input 4 Input 3 Input 2 Input 1
07 06 05 04 03 02 01 00
Input 4 Input 3 Input 2 Input 1
15 14 13 12 11 10 09 08
Input 8 Input 7 Input 6 Input 5
15 1211 0807 0403 00
16
3
16
2
16
1
16
0
DM word
Setting contents
Use Designation
0: Do not use.
1: Use.
00: -10 to 10 V
01: 0 to 10 V
10: 1 to 5 V / 4 to 20 mA
11: Same as 10 above
Mean Value Processing Setting
0000: No mean value processing
0001: Use mean value processing with 2 buffers.
0002: Use mean value processing with 4 buffers.
0003: Use mean value processing with 8 buffers.
0004: Use mean value processing with 16 buffers.
15 8 7 0
Use designation
Input signal range setting
Input 1: Mean value processing setting
Input 2: Mean value processing setting
Input 3: Mean value processing setting
Input 4: Mean value processing setting
Input 5: Mean value processing setting
Input 6: Mean value processing setting
Input 7: Mean value processing setting
Input 8: Mean value processing setting
m
m+1
m+2
m+3
m+4
m+5
m+6
m+7
m+8
m+9
Input Signal Range Setting
