What to do if conversion data does not change on Omron CJ1W-MAD42?
If the conversion data on your Omron I/O Systems isn't changing, ensure the input is set to be used. Also, check if the peak value hold function is active and turn it off if not needed. Use a tester to verify the input voltage or current is changing and check the Unit’s alarm flags for a disconnection.
Why value does not change as intended on Omron CJ1W-MAD42 I/O Systems?
If the value on your Omron I/O Systems isn't changing as intended, verify that the input device’s signal range matches the input signal range for the relevant input number at the Analog Input Unit. Make sure you adjust the offset and gain. If you're using the 4 mA to 20 mA range, ensure the voltage/current switch is turned ON.
How to fix inconsistent conversion values in Omron CJ1W-MAD42?
If you're experiencing inconsistent conversion values on your Omron I/O Systems, it might be due to external noise affecting the input signals. Try changing the shielded cable connection to the Unit’s COM terminal. Additionally, insert a 0.01-µF to 0.1-µF ceramic capacitor or film capacitor between the input’s (+) and (–) terminals. You can also try increasing the number of mean value processing buffers.
General| Brand | Omron |
|---|---|
| Model | CJ1W-MAD42 |
| Category | I/O Systems |
| Language | English |
Crucial warnings to prevent electric shock and serious injury.
Provides detailed technical specifications for the CJ1W-MAD42 Analog I/O Unit.
Outlines the step-by-step procedures for operating the Analog I/O Unit.
Provides guidance and diagrams for wiring the Analog I/O Unit.
Explains data exchange between the CPU Unit and the Analog I/O Unit.
Details analog input functions such as mean value processing and scaling.
Details analog output functions like output hold and scaling.
Describes the calibration process for input/output offset and gain.
Provides guidance on indicators, error flowcharts, and troubleshooting.
