What to do if conversion data does not change on Omron CJ1W-DA021 I/O Systems?
If the conversion data on your Omron I/O Systems isn't changing, ensure the input is set to be used. Also, check if the peak value hold function is active and turn it off if not needed. Use a tester to verify the input voltage or current is changing and check the Unit’s alarm flags for a disconnection.
Why value does not change as intended on Omron CJ1W-DA021 I/O Systems?
If the value on your Omron I/O Systems isn't changing as intended, verify that the input device’s signal range matches the input signal range for the relevant input number at the Analog Input Unit. Make sure you adjust the offset and gain. If you're using the 4 mA to 20 mA range, ensure the voltage/current switch is turned ON.
How to fix inconsistent conversion values in Omron I/O Systems?
If you're experiencing inconsistent conversion values on your Omron I/O Systems, it might be due to external noise affecting the input signals. Try changing the shielded cable connection to the Unit’s COM terminal. Additionally, insert a 0.01-µF to 0.1-µF ceramic capacitor or film capacitor between the input’s (+) and (–) terminals. You can also try increasing the number of mean value processing buffers.
General| Type | Analog Output Unit |
|---|---|
| Category | I/O Systems |
| Number of Channels | 2 |
| Number of Outputs | 2 |
| Power Supply Voltage | 24 V DC |
| Operating Temperature | 0 to 55 °C |
| Output Range (Voltage) | 0 to 5 V, 1 to 5 V, 0 to 10 V, -10 to +10 V |
| Output Range (Current) | 4 to 20 mA |
| Conversion Time | 1 ms |
| Current Consumption | 100 mA |
| Weight | 200 g |
Details critical safety measures such as not disassembling units with power supplied and providing external safety measures.
Lists crucial precautions for PLC and Unit use, including power supply, voltage limits, and proper wiring.
Explains the methods for data exchange between the CPU Unit and Analog Input Units via Special I/O Unit Area and DM Area.
Covers analog input functions like mean value processing, peak value hold, and disconnection detection.
Provides procedures for calibrating analog input offset and gain in adjustment mode.
Details indicators, error flowcharts, alarms, and troubleshooting steps for CS-series Analog Input Units.
Explains data exchange between the CPU Unit and Analog Output Units via Special I/O Unit Area and DM Area.
Provides procedures for calibrating analog output offset and gain in adjustment mode.
Details indicators, error flowcharts, alarms, and troubleshooting steps for CS-series Analog Output Units.
Provides procedures for calibrating analog input/output offset and gain in adjustment mode.
Details indicators, error flowcharts, alarms, and troubleshooting steps for the CJ1W-MAD42 Analog I/O Unit.
